Alarm cable 8*0.22 unshield

Location:China
Business Type:Manufacturer, Exporter
Brands:
Certificate:
Model:
Terms of payment and delivery:
Minimum order quantity:
Price:Consultation
Packing details:
Delivery time:
Payment method:
0
Views: 1,829
Contact Inquiry
  • 1)Structure: 8*0.22 ( 7*0.2) unshielded
    a> Conductor : CCA (TC,BC,TCCA are available)
    b> Cross sectional area of core  - 0.22 sq.mm
    c> Cable core: 8C
    d> Diameter of core section  - 0.52 mm
    e> Insulation: PVC
    f> Drain wire: yes
    g>Rip cord : yes
    h> Shield: no
    i> Jecket : PVC
    j>
    HS code -  85444920
    2)Application:
    These cables are used for installation in telecommunication, intercom,signaling and alarm system.
    This is suitable for the connection of contacts, detectors and sensors,
    infra-red as well as micro wave or mixed technology systems to the switchboard .
    3)Standard packing:
    100m/rolll, 100m/box ; 100m/plastic spool; 300m/wooden spool

    Item No. Decription Conductor Insulation Jacket Packing
    Spec. Nom.Thick Nom.Diam. Nom.Thick Nom.Diam.
      (mm) (mm) (mm) (mm)
    TYAC202 TC/BC/CCA/T  CCA
    Screened
    Unscreened
    Rip cord or No
    Drain wire or No
    2*7*0.2/0.22 1.5 1.05 0.5 3.1 Box
    Coil
    Drum
    Paper reel
    Plastic reel
    Wooden reel
    4*7*0.2/0.22 1.5 1.05 0.5 3.4
    6*7*0.2/0.22 1.5 1.05 0.6 4.1
    8*7*0.2/0.22 1.5 1.05 0.6 4.5
    10*7*0.2/0.22 1.5 1.05 0.7 5.1
    12*7*0.2/0.22 1.5 1.05 0.7 5.5
    20*7*0.2/0.22 1.5 1.05 0.7 7.2
